Single Axle Equipment Tilt Trailer

The Single Axle Equipment Tilt trailer is the ideal trailer for hauling any of your compact low-profile equipment.  It features a 7,000lb rated jack, pressure treated pine, wiring harness, multiple tie downs and a heavy duty bulkhead.  A hydraulic cushion cylinder with control flow valve lowers and raises the trailer for loading.  The low deck height and knife edge dovetail make this trailer ideal for scissor lifts or other low profile equipment.  Plus, the integrated toolbox allows for secure storage of tools and straps.

Full tilt and stationary deck configurations along with three suspension options, provide you ample options for your equipment needs.  Load and tow your equipment smoothly and easily with the Single Axle Equipment Tilt trailer.

Features

  • 5" Tube Frame
  • 5" Channel Tongue
  • 3" Formed Channel Crossmembers
  • Front Bump Rail
  • Posi-Lock Coupler with Safety Chains
  • Sealed Wiring Harness
  • Set-Back Jack
  • HD Diamond Plate Knife Edge Dovetail
  • Tread Plate Fenders
  • Torsion Suspension
  • Easy Lube Hubs
  • Breakaway Kit and Battery
  • Radial Tires on Steel Wheels
  • Industrial Grade Polymer Finish
  • 2" Treated Lumber Decking
  • Stake Pockets with Rub Rail
  • D-Ring Tie-Downs - 1/2” (4)
  • Lockable, Tongue Mounted A-Frame Toolbox
  • Full LED, DOT Compliant Lighting
  • Cushion Cylinder with Control Flow Valve

Available Options

Color Options

Not exact color match. Contact your local dealer for color samples.

  • Standard Black
  • Optional Red
  • Optional Gray

Specifications

  • 62" x 10' 6K
  • 78" x 12' 7.8K
  • 78" x 12' 10K
  • 78" x 12'+4' 7.8K
  • 78" x 12'+4' 10K
  • GAWR (lbs/axle)
  • 62" x 10' 6K 5200
  • 78" x 12' 7.8K 7000
  • 78" x 12' 10K 8000
  • 78" x 12'+4' 7.8K 7000
  • 78" x 12'+4' 10K 8000
  • GVWR (lbs)
  • 62" x 10' 6K 6000
  • 78" x 12' 7.8K 7800
  • 78" x 12' 10K 9900
  • 78" x 12'+4' 7.8K 7800
  • 78" x 12'+4' 10K 9900
  • Curb Weight (lbs)
  • 62" x 10' 6K 1390
  • 78" x 12' 7.8K 1900
  • 78" x 12' 10K 2250
  • 78" x 12'+4' 7.8K 2150
  • 78" x 12'+4' 10K 2450
  • Load Capacity (lbs)
  • 62" x 10' 6K 3810
  • 78" x 12' 7.8K 5100
  • 78" x 12' 10K 5750
  • 78" x 12'+4' 7.8K 4850
  • 78" x 12'+4' 10K 5550

Features and Specifications subject to change without notice. Please contact your local dealer for confirmation.
